Precipitation refers to any form of water–liquid or solid–that falls from the atmosphere and reaches the ground. Rain, snow, sleet, freezing rain, graupel, hail, and drizzle are all various forms of precipitation, depending on droplet size and temperature conditions. Fog and dew are not considered precipitation because they are condensation processes rather than falling water.
Precipitation is typically measured in millimeters (mm) or inches (in), with standard units expressing the equivalent depth of water that would accumulate if it were collected on a flat, impermeable surface. It is also common to express as intensity, which is the amount of precipitation falling in a given amount of time, such as millimeters or inches per hour (mm/h or in/h).
Why Measure Precipitation?
Precipitation is a crucial component of the Earth’s hydrological cycle. Surface water evaporates and rises into the atmosphere, where the water vapor condenses and forms clouds. When clouds become too full, some of the vapor turns liquid or solid and falls back to the surface.
This process drives the distribution of critical freshwater resources throughout the globe. Accurately measuring precipitation is important for a number of applications:
- Agriculture: Farmers rely on rain data to plan irrigation schedules, determine planting and harvesting times, and manage water resources efficiently.
- Water Management: Precipitation data is critical for managing drinking water sources including reservoirs, rivers, and groundwater supplies. It helps in predicting water availability and planning for drought or flood conditions.
- Weather Forecasting: Meteorologists use precipitation data to predict short-term weather conditions, including the likelihood of rain and snowstorms. This information is crucial for public safety and preparedness.
- Flood Mitigation: When intense rainfall arrives, accurate measurements are essential for implementing mitigation strategies to protect lives and property.
- Climate Studies: Long-term precipitation data helps scientists study climate change patterns and understand how shifts in precipitation impact ecosystems and human activities.
How Is Precipitation Measured?
Precipitation measurement techniques vary, with the simplest being manual observation of precipitation collected in a rain gauge. For measurement in long-term, automated monitoring systems, the most common devices used are tipping bucket rain gauges, radar sensors, and weighing gauges.
Tipping bucket rain gauges work by funneling water into a small bucket that tips like a seesaw when a specific amount of water accumulates. Each tip triggers a magnet or reed switch that produces an electrical pulse, which is counted by a pulse counter or converted to another digital format that can be recorded by a data logger. Since the volume of water of each tip is known, the total precipitation and intensity can easily be calculated by the number and frequency of tips.
Radar sensors emit electromagnetic waves and detect reflections from raindrops, snowflakes, or other precipitation particles. Using the Doppler effect, radar sensors are able to determine drop speed and size. These parameters are then used to calculate precipitation quantity and type.
Weighing rain gauges, also known as gravimetric rain gauges, measure precipitation by weighing the amount of water collected in a container. As precipitation accumulates, the weight of the container increases, which is measured by a load cell or other weighing mechanism. The weight is then converted to a precipitation depth measurement. Algorithms to compensate for wind, temperature, and evaporation may be implemented to further improve accuracy.
Other types of gauges such as optical or acoustic are also used in some applications. Optical gauges use infrared light to measure water droplets landing on the surface of a lens. While less accurate and limited to rain measurement, they can be a cost-effective alternative to tipping buckets in situations where accuracy is not as critical.
An acoustic sensor uses a piezoelectric detector to measure the impact of droplets falling on the sensor surface. The droplets produce acoustic signatures based on the drop size and type. The acoustic signatures are converted to a voltage or other measurable signal, and algorithms taking into account the measurement surface size can distinguish precipitation type, quantity, and intensity.
How to Select a Precipitation Gauge?
With all of the different measurement technologies available, there are several factors to consider when selecting a precipitation gauge. These include accuracy, measurement range, maintenance needs, and environmental conditions.
Generally speaking, a weighing gauge will be the most accurate measurement device across all precipitation types. However, cost and ease of deployment may require selection of a simpler sensor technology. In such cases, ensure that the sensor meets the required precision for the application.
Most sensors have a sufficient measurement range to cover the spectrum of normal rain events. However, in regions with high rainfall, a larger capacity gauge may be necessary, while areas with low precipitation may require a more sensitive instrument.
Consider also the maintenance requirements associated with each sensor type. Some may have a surface that naturally sheds debris and moisture buildup, while others like tipping bucket gauges are subject to interference from leaves, insects, and other debris. Remote locations that cannot be frequently visited may be better suited with a relatively low-maintenance device.
Lastly, evaluate the sensor against the local environmental conditions to which it will be exposed. The sensor must be able to withstand temperature extremes, wind, and potential impacts from debris or animals.
If the environment in which the sensor is deployed will frequently experience sub-freezing conditions, choosing a sensor type that is well-adapted for solid precipitation like snow and sleet may be favorable. Weighing gauges and radar sensors perform well in such cases, though other sensor types can still work well if equipped with heating.
Sensor selection depends in part on what forms of precipitation should be measured. Heated sensor models can enable or improve accuracy of measurements marked with *.
What to Consider When Preparing a Precipitation Gauge?
Calibration and proper shielding/protection of the sensor are critical for accurate precipitation measurement. Most sensors arrive with a factory calibration and are ready for deployment. However, some include calibration procedures that the user can perform. These should be reviewed and, in some cases, practiced before installation to ensure proper sensor maintenance.
Some sensor types are vulnerable to interference from debris, birds, wind, and other sources. Many include accessories to mitigate interference. Examples include a debris filter on a tipping bucket rain gauge, bird spikes to prevent birds from perching atop the sensor, and wind screens to mitigate the potential for wind-related measurement error. Use these accessories as appropriate for the sensor type and measurement location.
In the case of radar sensors, care should also be taken to ensure that they are not deployed in the vicinity of other radar devices that can cause measurement interference, such as traffic counting radars. Maintain a minimum distance to avoid interference, or use different measurement timing or shifting frequencies.
How to Deploy a Precipitation Measurement System?
Site selection is critical for establishing a precipitation gauge that will be able to achieve its specified accuracy. Gauges must be installed with proper height and distance from potential obstructions.
Ensuring that precipitation gauges are installed with sufficient clearance from obstructions is essential for accurate measurement.
Sensor manuals and meteorological standards will often specify the required or minimum recommended distances. In most cases, the precipitation gauge will be mounted either at the top of a weather station mast or tower, or on a dedicated mount located a minimum distance from the primary mast or tower and any other taller obstructions like trees or buildings.
Sensor designs typically include a pole-mount or other similar bracket for secure mounting onto masts and towers.
Conclusion
Precipitation measurement is an essential aspect of comprehensive meteorological observation systems. From daily weather forecasts to long-term climate studies, a wide range of applications benefit from accurate precipitation data.
Many different technologies exist for long-term monitoring of precipitation in automated measurement systems. Through careful consideration of the site conditions and accuracy requirements of any particular application, climate scientists, environmental managers, and meteorological organizations can design a system to obtain high-quality data.
